Baader Morpheus 6.5 mm 76° Widefield Eyepiece – 1.25"/2"

Baader Morpheus 6.5 mm 76° Widefield Eyepiece – 1.25"/2"

DESCRIPTION

The Baader Morpheus 6.5 mm 76° eyepiece delivers exceptional sharpness across the entire field of view. With a premium 8-element design in 5 groups and lanthanum glass, it provides high contrast, flat field images free of distortion. Phantom Group multi-coatings maximize light transmission and clarity.

Its 20 mm eye relief ensures comfortable viewing, even with eyeglasses or binoviewers. The eyepiece features dual 1.25" and 2" barrels with anti-slip micro-knurling for secure fit without problematic undercuts. The integrated M43 thread enables direct camera adaptation for projection photography using Hyperion Digital T-Rings.

It includes two eyecups (standard and winged), a M43/M43 extension, a belt holster, focal length indicator clip, and glow-in-the-dark engraving for quick ID in the dark.

TECHNICAL DATA

• Product Code: 2954206

• EAN: 4047825030290

• Manufacturer: Baader Planetarium

• Series: Morpheus

• Focal Length: 6.5 mm

• Apparent Field: 76°

• Eye Relief: 20 mm

• Lens Elements/Groups: 8 in 5 groups

• Filter Thread: Yes

• Camera Thread: M43

• Connections:

  • Input: M28.5

  • Output: M43 / 1.25" (31.75 mm) / 2" (50.8 mm)

• 1.25" Barrel Length: 24 mm

• 2" Barrel Length: 21 mm

• Outer Diameter: 55 mm

• Field Stop Diameter: 9.07 mm

• Height above Reference Plane: 90.2 mm

• Net Weight: 370 g

• Luminescent Labeling: Yes

• Included Accessories:

  • 3 dust caps (1.25", 2", 49 mm)

  • 2 eyecups (rubber/metal, winged)

  • M43/M43 extension

  • Belt pouch

  • Focal length indicator clip
