Baader Morpheus 9 mm 76° Widefield Eyepiece – Visual and Projection

Baader Morpheus 9 mm 76° Widefield Eyepiece – Visual and Projection

DESCRIPTION

The Baader Morpheus 9 mm eyepiece delivers a distortion-free, sharp 76° field with high contrast and clarity. With 21 mm of eye relief, it provides excellent comfort even for eyeglass users. The optical group consists of 6 elements in 4 groups, fully treated with Phantom Coating® Group and featuring blackened lens edges for maximum contrast and minimal internal reflections.

The body diameter of 55 mm makes it perfectly suited for binoviewer use. A dual 1.25"/2" barrel without large undercuts but with Safety-Kerfs ensures secure grip without snagging. The integrated M43 thread allows afocal and classic projection with T-rings.

A photo-luminescent label helps identify the focal length in the dark. The Morpheus 9 mm is ideal for planetary, lunar and deep-sky observations, and as a projection eyepiece for photography.

Included are two eyecups (foldable and winged), M43/M43 extension, focal length clip, dust caps, and a Cordura holster that attaches to a belt or tripod.

TECHNICAL SPECIFICATIONS

• SKU: 2954209

• EAN Code: 4047825030283

• Manufacturer: Baader Planetarium

• Net weight: 0.39 kg

• Focal length: 9 mm

• Apparent field of view: 76°

• Eye relief: 21 mm

• Outer diameter: 55 mm

• Lens configuration: 6 elements / 4 groups

• Length above reference plane: 76.5 mm

• Barrel length (1.25"): 24 mm

• Barrel length (2"): 21 mm

• Filter thread: yes

• Photo thread: M43

• Connections:

  • 1.25" (31.75 mm)

  • 2" (50.8 mm)

  • M43 (photo/video)

  • M28.5 (lens side)

• Luminescent labeling: yes

• Included accessories:

  • 1.25" and 2" dust caps

  • Foldable rubber eyecup with metal thread

  • Winged eyecup

  • Cordura eyepiece holster

  • Focal length indicator clip

  • M43/M43 extension ring
