iOptron HAE43C AZ/EQ SWG with Handset

iOptron HAE43C AZ/EQ SWG with Handset

Description

The iOptron HAE43C AZ/EQ SWG with Handset is a next-generation hybrid mount using Strain Wave Gear drives on both RA and DEC axes. It provides an outstanding weight-to-payload ratio and excellent precision.
Weighing only 5.7 kg, it supports up to 20 kg of payload without a counterweight. Its CNC-machined aluminum structure, black anodized finish, and solid construction ensure strength and stability for years of use.
This version includes the Go2Nova 8411 OLED handset with a database of approximately 212,000 celestial objects, offering accurate and responsive GoTo operation.
It features an electronic friction brake for safety during power interruptions, an integrated ST-4 autoguide port, and a dual Vixen/Losmandy-D saddle.
The HAE43C can operate in equatorial mode for astrophotography or in alt-azimuth mode for visual observation, making it an excellent portable mount for both field and home setups.

Technical Specifications

• Type: Strain Wave Gear Alt-Az/Equatorial mount

• Payload capacity: 20 kg (44 lb) without counterweight

• Mount weight: 5.7 kg (12.6 lb) including saddle

• Payload/mount ratio: 3.51

• Reduction: RA 640:1, DEC 480:1

• Gear period: 270 s

• Periodic error: < 36 arcsec (< ± 18 arcsec)

• Motor: Stepper motor

• Structure: CNC-machined aluminum, all-metal

• Finish: Black anodized

• Brake: Electronic friction brake

• Control: Go2Nova 8411 OLED handset

• Database: ~212 000 celestial objects

• Autoguiding: ST-4 port

• Communication: USB-C and Wi-Fi

• Polar scope: Optional

• Saddle: Dual Vixen/Losmandy-D

• Firmware upgrade: Yes

• Power supply: 12 V DC, 5 A (5.5/2.1 mm plug)

• AC adapter: 100–240 V included (indoor use)

• Power consumption: 0.7 A (tracking), 1.2 A (GoTo)

• Operating temperature: -20 °C to +45 °C

• Accessories: Aluminum carrying case

• Warranty: 2 years
