ZWO ASI678MM CAMERA

ZWO ASI678MM CAMERA

Description

The ZWO ASI678MM is a monochrome camera dedicated to planetary and high-speed astrophotography. It is equipped with a Sony STARVIS 2 IMX678 CMOS sensor in 1/1.8" format, offering a native resolution of 3840 x 2160 pixels. The STARVIS 2 technology ensures enhanced near-infrared sensitivity and extremely low noise, ideal for lunar, solar, and planetary observation.

Its exposure range from 32μs to 2000s allows flexibility across various imaging scenarios, including some deep-sky objects.

The ASI678MM features a 12-bit ADC, integrated 512 MB DDR3 buffer for smooth data transmission, and a USB 3.0 interface ensuring high-speed data transfer.

It is compatible with ZWO filters and filter wheels and easily mounts via its M42x0.75 thread or the built-in 1/4" tripod mount.

Caractéristiques techniques

• Sensor : Sony IMX678 monochrome

• Sensor type : CMOS

• Sensor format : 1/1.8"

• Resolution : 8.29 MP (3840 x 2160 pixels)

• Pixel size : 2.0 µm

• Sensor size : 7.68 mm x 4.32 mm

• Sensor diagonal : 8.84 mm

• Frame rate : up to 47.5 fps at full resolution

• Interface : USB 3.0

• Buffer : 512 MB DDR3

• ADC : 12-bit

• Exposure range : 32 µs to 2000 s

• Thread : M42x0.75

• Tripod mount : 1/4"

• Weight : 126 g

• Compatibility : Windows, macOS, Linux

• Dimensions : 62 mm diameter, 36 mm height

• Cooling : no

• Usage type : planetary, lunar, solar, light deep-sky
