Tecnosky 0.8× Field Flattener/Reducer for APO 115/800 mm

Tecnosky 0.8× Field Flattener/Reducer for APO 115/800 mm

Overview

The Tecnosky 0.8× Reducer/Flattener is designed for 115 mm aperture, 800 mm focal length apochromatic refractors. It reduces the focal length by 20%, increasing brightness and field of view, while correcting field aberrations for sharp images across the frame.

Compatible with full-frame sensors, it offers a corrected field of 42 mm. It threads directly onto 3" focusers with M68x1 mm threads and connects to cameras via M48x0.75 mm threads.

Technical specifications

• Focal reduction: 0.8×

• Optical elements: 3

• Corrected field: 42 mm (full-frame)

• Backfocus: 55 mm

• Telescope connection: M68x1 mm

• Camera connection: M48x0.75 mm

• Total length: 80 mm

• Compatibility: APO 115/800 mm refractors or similar

Optical performance

• Increased brightness: Shorter focal length allows for reduced exposure times

• Field correction: Sharp images across the field, suitable for full-frame sensors

• Versatility: Compatible with various 115 mm apochromatic refractors

Compatible accessories

• Refractors: Tecnosky APO 115/800 mm V3 Triplet

• Cameras: Full-frame DSLRs, CCD/CMOS cameras with M48 threads

• Adapters: M48 T-rings for Canon, Nikon, Sony mounts, etc.

Key features

• 3-element optical design for optimal correction

• Full-frame sensor compatibility

• Easy installation with standard threads

• Significant improvement in astrophotography image quality
